Fujifilm VXR Veterinary System

VXR is Fujifilm’s dedicated veterinary room. The generator lives in the table so the room stays clean. 32 kW on 220–240 V, or capacitor-assisted 32 kW on 100–120 V so a standard clinic circuit can still make the exposure. Four-way float, urine trap, removable 10:1 grid, 100 cm SID, 17×17 bucky.

The console on the tube head is the product: anatomical programs by species and body region, user-programmable techniques, four-point kV / mA / time / mAs display. Virtual Grid (option) for large animals without a physical grid. Dynamic Visualization II (option) on the FDR console.

Detectors: FDR SE Lite for an economical wireless ISS package, FDR ES for FDX Console, or the cassette the hospital already owns. We also sell InnoVet when that is the better veterinary standard — we will recommend VXR or Versa DR based on the hospital, not a single default.

What matters in the room

• 32 kW or capacitor-assisted 32 kW in the table
• Runs on standard clinic electrical infrastructure
• 4-way floating top and urine trap
• Species anatomical programs on the tube-head touchscreen
• 17×17 bucky — ES, SE Lite, or existing cassette
• Optional Virtual Grid and Dynamic Visualization II

How this system is used

• Veterinary
• Equine & Field
